LaserPro Spirit is designed with the operator in mind and carrying various innovative features, reliable mechanics, and excellent output quality.

LaserPro Spirit is the missing piece in your operations puzzle, putting you on track for continued growth in your engraving and cutting business!

Work  Area		25 x18 in. (640 mm x 460 mm) Extendable to 29x18 in. (740 x 460 mm)
Maximum Part Size (W x L x H)	All doors closed	31.5 x 22.4 x 6.5 in. (800 x 570 x 165 mm)
	All doors open	26.8 x ∞ x 6.5 in. (680 x ∞ x 165 mm)
Table Size		31.1 x 20.9 in. (790 x 530 mm)
Dimensions		44.3 x 28.3 x 39.6 in. (1125 x 720 x 1005 mm)
Laser Source		12 to 60W 10.6-µm sealed CO2 Laser / 20W 9.3-µm sealed CO2 Laser
Cooling		Air-cooled, Operating environment temperature 15° - 30°C (60° - 86°F)
Drive		Closed-loop DC Servo control
Throughput*		245.5 in² / hr (1584 cm² / hr)
Throughput* with SmartACT Enabled		283.4 in² / hr (1828.8 cm² / hr)
Speed Control		Adjustable from 0.1-100% of 60IPS (Up to 16 color-linked speed settings per job)
Power Control		Available from 0~100% (UP to 16 colors linked power setting per job)
Distance Accuracy		0.254mm or 0.1% of move, whichever is greater
Z-Axis Movement		Automatic
Focus lens		Standard 2.0", optional 1.5", 2.5" & 4.0" available
Resolution (DPI)		Available 125, 250, 300, 380, 500, 600, 760, 1000
Computer Interface		Standard printer port and USB 2.0** port
Compatible Operating Systems		MS Windows
Memory Buffer		32MB standard
Display Panel		4-line LCD panel showing current file name, total working time, laser power, engraving speed, file(s) loaded into memory buffer, setup and diagnostic menus
Safety		Class 3R for red pointer
Operation Voltage		100-240 Volt AC Auto Switching for 30Watt and below;  200-240 Volt AC Auto Switching for 40Watt and above models
Power Consumption		700 W - 3300 W
Air Exhaust System		External exhaust system is required, one 4 in. connection on the back of the machine

*Throughput value represents the Max. number of 8 in. x 10 in. 500DPI raster jobs that can be done per hour.

** File transmission at USB 2.0 Full Speed rate Specifications are subject to change without prior notice.
