Wit Color Ultra 9200 Series
wit
Information:

Beyond Your Expectation!

Optional for 1 and 2 Epson DX5 Print Heads.

Optional for 1.6/2.2/2.6/3.3 Meters.

Micro piezoelectric printing technology

Adopt the new-type micro piezoelectric printhead with a resolution of 1440dpi. Each printhead has 1440 nozzles. Two printheads are in parallel. The total number of nozzles is 2880. Dual four-color mode. Achieve single-color coverage of 2-inch printing area per travel while providing high precision.

Variable ink drop technology

Depending on different output types, variable ink drop technology can generate 3 kinds of micron ink drops ink different sizes. Ink size is freely optional between 3.5pl-21pl. Achieve a pretty, fine, smooth and particle-free tone transition. In conjunction with RIP software, variable ink drop technology makes this printer even highly applied in appreciation field for flawless quality.

Eye-catching printing speed (original technology)

The single PASS printing breadth of Wit-Color ULTRA 9000 reaches 2 inches, while that for common micro piezoelectric printer is only 1 inch. The printing speed of Wit-Color ULTRA 9000 reaches up to 50m2/h (production mode).

Random fuzzy dotting technology (original technology)

Random fuzzy dotting technology can solve the line drawing and white strip caused due to the blocking of nozzles, which are often seen with other inkjet printers and have obsessed producers. Wit-Color ULTRA 9000 can overcome this problem.

RIP Support USB2.0 data transmission interface (standard configuration)

Achieve high-speed transfer and cluster operation, thus quickening your daily work speed. Wit-Color ULTRA 9000 standard configuration supports fully functional Maintop Rip software featured by standard ICC color management.

Fully new mechanical architecture (original technology)

Wit-Color ULTRA 9000 adopts a linear guide rail driving architecture, XY axis grating positioning and lightweight and rigid rack, including 16-line ink feeding system, front, center and back platform heating, air suction, waste ink collection system, front and back paper rolling, 8-fan air drying system, etc. Its weight is merely 260kg, achieving the balance between structural rigidity and compactness.

Low purchase cost (never before)

The biggest advantage of Wit-Color ULTRA 9000 is that it can achieve a very low ownership cost on the basis of such high performance. That is to say, equipment unit price is low and use cost is low. It is suitable for multiple applications from aqueous printout to eco-solvent, sublimation, etc and realizes the perfect integration of high precision, high speed, multiple functions, lightweight and low cost.

Technical Specification:

Printer Model

ULTRA 9200 3301S ULTRA 9200 3302S
Print Head Quantity Epson DX7 1pcs Epson DX7 2pcs
Printing Width 3.2m/ 2.2m/ 1.8m
Printing Speed Resolution Printing Speed H1 Printing Speed H2

360×1080dpi(3Pas)

31m^2/h 62 m^2/h
360×1440dpi(4Pas) 21m^2/h 42 m^2/h
360×2160dpi(6Pas) 16 m^2/h 32 m^2/h
360×2880dpi(8Pas) 12 m^2/h 24 m^2/h
Color Mode 16.7million CMYK
Ink CMYK W:Waterbased Inks S: Eco-solvent Inks
Media Media width 3.2m
Media Handling Roll to Roll+Auto Roll Up
Media heating Pre & Post-Media Heating
Media Drying Cool Fans / Thermal Fans(Optional)
Media Types W Series: Water based on media(Photo Paper, Vinyl, PP, Film, etc)
S Series: Outdoor Eco-solvent based roll media(Flex, Vinyl, Leather, etc)
Image Format TIFF, JPG, EPS, PDF
RIP Software Maintop (Photo print Optional)
Interface USB2.0 (Windows 2000NT / XP, etc)
Operation System Windows XP / Win 7 Workstation
Power Supply AC220V 50HZ±10%, UPS is required
Power 5000W
PC Configuration System: Window XP SP2 (English Version)
Win7 32bit (Professional or Ultimate Version)
CPU: Intel Dual Core 15 RAM:2GB(at least)
Hard Disk: SATA 640G Hard Disk Format: NTFS
VGA Card: SDC ATI 1G CD Rom: DVD Rom
Space for Disk C: 100G at least>
Temperature / Humidity Temperature 15-32°C, Humidity 30-90%
Packing Size L/W/H: 4.62×1.08×1.68m
G.W. / N.W. 600kgs / 475kgs
Remarks: The data is subject to change without prior notice. The speed will be varied due to different PC

settings.

Download PDF »»

Features:

A.Single Media Feeding and Take-up system.

B.Single Media Feeding and Take-up system + Monitor.

C.Dual Media Feeding and Take-up system.

D.Dual Media Feeding and Take-up system+ Monitor.
